The apparatus consists of one brass cup and cover fitted with shutter mechanism test flame arrangement (Oil test jet or Gas test jet) and stirrer placed on a water bath made of Stainless steel sheet, double walled. The outer jacket of the water bath is fitted with a stand.
- Brass Test cup with handle removable cup cover.
- Spring operated rotating shutter having pilot jet for ignition.
- Air Bath which is covered with Dome shape metal top
- Heater with energy regulator.
The setup comprises of hammer tone finish, Stainless steel bath with drain plug, electrical heating arrangement, with silver plated oil cup with precision stainless steel jet, ball valve, cover, thermometer clip, stirrer and suitable stand with leveling screws.
The apparatus consists of stainless steel bath with oil cup. The bath has a lid which contains water cooling tube, two handles with two stirring blades, thermometer socket and a straight heater. Two jets one universal and one furol can be screwed to the cup by a handle.
- Cup heating plate to specific dimensions, thermometer clip and test flame applicator with swivel joint for passing over liquid surface in the prescribed manner.
- Heater is controlled by energy regulator fitted to the apparatus.
- Cooling bath made of stainless steel sheet.
- Stand unit with drain plug and cover with provision for fitting thermometer.
- Equipped with a filling aperture for adding freezing mixture.
- Thermostatically controlled heating unit
- Motorized stirrer arrangement for stirring the liquids
- Energy regulator for heating control
- Borosil make Thin film tube of 400 ml capacity for placing the sample
It consists of Calorimeter vessel with bomb support & insulating base, Water Jacket, Combined lid for calorimeter vessel & water jacket, Stirrer, Fine adjustment valve with built in pressure gauge, Safety Relief Valve fitted on gas filling tube adapter, Pellet Press, Ignition Wire – Nichrome
Orsat gas analysis apparatus with three absorption pipettes of two compartment type,100 ml Gas Burette with outer jacket, manifold with stopcocks, and aspirator bottle, for the analysis of CO, O2, CO2, particularly in fuel and furnace gases, complete in wooden cabinet with sliding doors.
- Spun Sheet Iron Crucible 25 cc capacity
- sheet hood and sheet iron block
- Meker burner, Porcelain crucible
- Nichrome Triangle
- Inner crucible nd Outer crucible with lid
- Double walled water bath
- Inner chamber is made of mirror polished - SS from corrosion resistance effect.
- Exterior body is fabricated from Mild steel material
- Auto-Tune Digital PID temperature controller
- Metal shield to support distillation flask with Geared Height Adjustment Device.
- PT 100 Temperature sensor, Slot for vapor tube.
- Non‑refrigerated cooling bath ( with ice ) and supporting stand
- Cast aluminum base with an iron stand
- Built‑in spirit level and leveling screws
- Brass cone, container, weight and Digital time controller
- Brass chromium plated rod slide through the lower portion of the arm.
The apparatus consist of 500 ml heat resistant glass with neck having ground glass joint, a condenser made of heat resistant glass, receiver - also made of heat resistant glass with ground glass joint leading to the flask and graduated tube. Capacity of receiver will be 2 or 10 ml.
