Shell and Tube type Heat Exchanger
- Shell and tube type heat exchanger to transfer the water heater
- Industrial type immersion water heater to heat the water
- Thermocouple sensor to sense the inlet and outlet temperature
Bare and Finned Tube Heat Exchanger
- Bare tube heat exchanger vertically mounted on frame
- Finned tube heat exchanger vertically mounted on frame
- Pressure gauge to monitor the steam pressure
Horizontal Condenser Apparatus
- This unit consists of water heater, horizontal condenser, rotameter, temperature sensors with indicator, etc. to study the performance of horizontal condenser.
Packed bed Column Apparatus
- The setup is filled with a ceramic material
- MS with fiber coated reservoir tank and measuring tank
- U tube Manometer to measure the pressure drop
Agitated Vessel Apparatus
- This unit consists of water heater, agitated vessel, temperature sensors with indicator, etc. to study the performance of agitated vessel.
Single Effect Evaporator
- Evaporator tank (closed type) setup assembly fixed on frame
- One reservoir tank to store the water
- Pump to circulate the water
