• DCS controller, Distributed I/O Module and IOT module fixed on control panel
• Control switches, Indicators, Meters, Test points, Rack provided
• SPDT Switches/Push button provided to simulate the Digital inputs.

• 50 SPDT Switches provided to simulate the Digital inputs.
• 50 LEDs provided with fuse protection to simulate the Digital outputs.
• Digital voltmeter, ammeter to display the Voltage and Current

This PLC trainer consists of PLC, Demonstration panel, Programming software to study the concepts, and programming of programmable logic controller.

This  PLC  trainer  consists  of  Demonstration  panel,  PLC  software  to  study  the concepts,  and  programming  of  programmable  logic  controller.  Demonstration panel consists of PLC, Switches and LEDs to demonstrate input, output functions, etc.

• Sump tank with miniature pump to circulate the water.
• Transparent process tank with setup.
• In-Built Power Supply and Driver circuit
• Connectors for external interface from PLC.

• Water bath / Mini furnace (100°C) with cooling fana a heat source.
• In-Built High Power relay circuit & power Supply.
• Signal conditioner
• Digital display to indicate the Water bath temperature

• MS with powder coated pressure tank
• Pressure sensor
• Pressure gauge
• Solenoid valve with driver
• Digital LED display to moniter the tank pressure.

• Conveyor movement mechanism with motor pulley.
• Stepper / Servo motor
• Metal sensor to sense the optical presence.
• Connectors for external interface from PLC

• Lift arrangement and conveyor belt.
• Stepper/Servomotor
• Lift position sensor with indicators
• All input and output points are terminated in front panel to interface with PLC’s.

• Relay driver with lamps (230V).
• In-built Power Supply.
• Switches provided.
• Connectors for external interface from PLC
• Mimic diagram sticker with metal cabinet.

• Turbine flow sensor mounted on pipe line.
• Variable area flow meter mounted on pipe line
• DC motor with pump
• In-built Power supply
• Digital display

• Sensor to sense the presence of car.
• Different color LED provided
• Stepper motor to close the door.
• Stepper motor driver
• Connectors for external interface from PLC
• Powder coated metal frame setup

• High torque stepper/DC motor
• Stepper/DC motor driver circuit
• Water tank with compact DC pump and driver circuit
• Solenoid valve with relay driver circuit
• In-Built power supply and mimic diagram

• Double acting pneumatic cylinder fixed on horizontally in the loading unit
• Small square wooden block as a stamping job stacked vertically in a loading unit

• Three axis controlled table top model laboratory drilling machine
• Main Spindle carrying drill bit driven by high torque motor
• Drilling for lighted metals/materials (viz. Acrylic, Plastic, Wood, Aluminum)
• Screw rod mechanism

• Traffic light controller setup
• Inbuilt power supply
• LED’s Provided on each side
• All input and output terminals are terminated in front panel to interface with PLC’s
• Powder coated metal cabinet

• DC Motor fixed on metal frame
• MOSFET based power driver circuit
• Speed sensor to sense the motor speed
• Voltage source for internal testing purpose

• DC Motor fixed on metal frame
• In-Built RELAY based power driver circuit
• Speed sensor to sense the motor speed
• Built in power supply

• Motor fixed in metal frame
• Power driver circuit
• Speed sensor to sense the motor speed
• Built in power supply
• Digital LED Green display to indicate motor speed

• Immerson Heater
• Stirrer to mix the process tank water
• Process tank to store the water
• Transparent storage tank with level switches provided

• 3 phase, 16Amps main contactor
• 6A overload relay
• Start and stop push button switches, Fuses provided
• Power wiring termination
• Control wiring termination
• Powder coated metal cabinet.

• 16Amps, 3 phase contactors
• Start and stop push button switches, Fuses provided
• Power wiring termination
• Control wiring termination
• Powder coated metal cabinet

• 3 phase 16Amps contactors
• Start and stop switches provided
• 3 timers provided
• Provision to wire control and power wiring
• Provision to wire external resistances in the rotor circuit

• Miniature DC motor fixed in front panel
• DC bulb fixed on the plate.
• PWM based DC power driver
• Relay driver with bulb indicator
• Proximity sensor mounted in panel.
• Switch with LED indicator
