This unit consist of Conical tank, Control valve, I/P convertor, Rotameter, Pump, level transmitter, air regulator etc., to study the Non Linear system.
The objective of this experimental setup is to study control of level in a spherical tank which is a non-linear system. The set up consist of spherical tank, storage tank, rotameter, control valve, level transmitter and other accessories.
This advanced research unit consists of Conical tank, Spherical tank, Control Valve, I/P Converter, Pumps, Level Transmitters, etc., to study the Interacting System.
Three Tank System is one of the most advanced industrial prototypes learning equipment designed and fabricated by latest technology. This experimental has been designed to expose the students to such a practical application system.
This system is especially designed to understand the working of Four Tank System (Interacting & Non-Interacting) advance study in complex systems. It is a combination of two double tank system (Quadruple Tank).
pH control unit has been designed to enable the students to go through the complete design procedure and finally verify the performance of pH Control System.
This advance process control system consists of process control components like Water Bath, Control valve, I/P converter, Heater, rotameter, Temperature Transmitter and Smart Differential pressure Transmitter etc. to establish a closed loop control of CSTR process.
This advance multi process control trainer consists of Control valve, I/P Converter, Flow Transmitter, Process tank, Storage tank, Rotameter, Level Transmitter, Air Regulator and a powerful data acquisition card etc., provided to control the process.
This system is especially designed to understand the working of Multi Tank System advance study in complex systems. It is a combination of two double tank system (Quadruple Tank). It is well-arranged frame work with Level Transmitters, Control Valves, Pumps, Flow meters etc…
This system is especially designed to understand the working of Multi Tank System advance study in complex systems. It is a combination of two double tank system (Quadruple Tank) Nonlinear system, Temperature heat exchanger.
Temperature Process Controller using Heat Exchanger is one of the most advanced and learning equipment designed and fabricated by latest technology. This unit consists of Heat Exchanger, Control Valves, I/P Converters, Flow Transmitters, SS Process tank with Controller, Rotameters,
This advance cascade control trainer consists of Control valve, I/P Converter, Flow Transmitter, Process tank, Storage tank, Rotameter, Level Transmitter, Air Regulator and a powerful data acquisition card etc., provided to control the above process.
