PID Controller (JIPID-101)
 web.jpg)
- Simulated 1st ,2nd , 3rd order system of type 0 and type 1 system
- PID section with adjustable proportional gain, derivative and integral time constants …
Lead Lag Compensation (JILL-102)
 Web.jpg)
- Signal Generator to generate sine & square waveforms
- Compensation network implementation through built-in variable gain amplifier
- Lead, Lag, invertor blocks
- Sine, Square amplitude and ...
AC Position Control System (JIAP-105)
- AC geared servo motor are permanent split capacitance induction motor
- IC based analog / Digital PI controller
- Thyristor based power driver circuit
DC Position Control System (JIPC-103)
- IC based analog / Digital PI controller
- Feedback sensor (0-360)˚ with electrical output
- MOSFET based power driver circuit
- 12V gear motor for...
Stability Analysis of Linear System (Stable / Unstable) (JISA-107)
- Square waveform and variable DC voltage source
- Error detector, Controller with proportional and Process
- Separate Stable and Unstable block
- Regulated power supply with test points
Synchro Transmitter and Receiver (JIST-104)
- Synchro transmitter with calibrated dials
- Synchro receiver with calibrated dials
- Step down transformer
Wheatstone Bridge with Source (JIWB-151)
- Four arms with suitable terminal connectors
- Digital display for bridge balancing condition
Kelvin Double Bridge with Source (JIKB-152)
- Four arm with suitable terminal connectors
- Three resistance are provided in each of the two arms
Schering Bridge with Source (JISB-153)
- Four arm with suitable terminal connectors
- Signal generator and audio amplifier with speaker
- Four capacitance are provided in one of the arms
- Inbuilt capacitance bank provided [4 values]
Maxwell Bridge (JIMB-154)
- Four arm with suitable terminal connectors
- Signal generator and audio amplifier with speaker
- Four resistance are provided in one of the arms
- Inbuilt Inductor bank provided ...
Anderson Bridge with Inductance source (JIAB-155)
- Four arm with suitable terminal connectors
Hay’s Bridge with Inductance source (JIHB-157)
- Four arm with suitable terminal connectors
- Signal generator and audio amplifier with speaker
- Three resistance are provided in one of the arms
- Variable resistance provided...
De – Sauty Bridge with Source (JIDB-156)
- Four arm with suitable terminal connectors
- Signal generator and audio amplifier with speaker
- Three capacitance are provided in one of the arms
- Variable resistance potmeter provided...
Pressure Measurement Trainer (JIPR-05)
- Strain gauge based pressure sensor to sense the tank pressure
- Pressure tank to store the air pressure
- Foot pump and pressure tank
- Bourdon type pressure gauge
- ...
Temperature Measurement Trainer using RTD, Thermistor sensor (JIRT-10)
- RTD and Thermistor as a temperature sensor
- Signal conditioner for each sensor
- Resistance source provided for zero calibration
- Water bath as a heat source
- Digital display ...
Displacement Measurement Using LVDT (JILV-07) :
- LVDT sensor fixed on the calibration jig
- LVDT calibration jig with screw gauge
- Signal conditioner and Digital display
- Zero span adjustment knob
- Regulated power supply
Optical Sensor Trainer (LDR, Photo Diode)
- LDR, Photo diode as a optical sensor
- Variable voltage source
- Bulb and sensors
- Regulated Power supply
- Powder coated metal cabinet
Strain Measurement Trainer (JIST-02)
- Strain gauge sensor with 1Kg cantilever beam
- Slotted weights with hook
- Signal conditioner and Digital display
- Regulated Power Supply
- Zero, span adjustment knob
Flow Measurement Trainer (JIFL-501)
 3 web.jpg)
- Water flow sensor mounted on the pipe line
- Digital flow indicator
- Reservoir tank with suitable pump
- Rotameter to measure the flow rate
- Powder coated metal frame
Power and Energy Measurement Trainer (JIPE-301)
- Single phase auto transformer
- Magnetic disk / analog type energy meter to measure energy
- Analog Ammeter, Voltmeter and Wattmeter
- 5 No’s of bulb act as a load
- ...
Instrumentation Amplifier Trainer (JIIA-09)
- One Potentiometer with millivoltage (0-50) mA source
- Instrumentation amplifier circuit board
- Different gain selection (10,100 gain)
- Zero calibration potmeter and Digital display
- ...
Analog to Digital Converter Trainer (JIAD-401)
- Analog to Digital Converter
- Triggering pulse generated by 555 IC
- 8 No of LED’s to simulate the output
- Potentiometer to vary the DC input voltage feed to ADC
- Built-in power supply
Digital to Analog Converter Trainer (JIDA-402)
- Two types of D to A converter
- 8 No of SPDT switches
DC Motor Speed Measurement Using Photo Electric Pickup
- DC Motor with Speed Sensor mounted on a frame
- Variable voltage source, F/V converter
- fixed on the frame
- Digital display
Torque Measurement Trainer (JITO – 06)
- Strain gauge based reaction type torque sensor mounted in L angle
- L angle and 1m length fulcrum arm
- Slotted weight 100 gms (1 Kg) with hooks
- Digital display to indicate the torque...
Current Generator Kit
- Voltage to Current converter
- Digital display to indicate the output current (0-20 mA)
- Voltage source (0-5) V DC
- Regulated power supply
DC Motor Speed Measurement Coupling Tacho Generator
- DC Motor with Speed Sensor (Tachogenerator) mounted on a frame
- Speed Range: 0 to 500 rpm to vary the motor speed
- Variable voltage source, F/V converter
- Digital display
Stepper Motor Control System
- Highly torque stepper motor
- Position feedback sensor fixed
- PWM based intelligent power driver
- Digital Controller and Digital display
- Regulated power supply
